Thickness: 0.2-0.5 mm
• High Damage Threshold
• Low Cost
Diameter
Part No.
WPL2610
WPL2612
WPL2615
WPL2620
WPL2625
Specifications:
Material:
Optical grade Crystal Quartz
Dimension Tolerance:
+0.0,-0.2mm
Wavefront Distortion:
l/8@633nm
Retardation Tolerance:
l/500
Surface Quality:
20/10 Scratch and Dig
AR Coating:
R<0.2% at center wavelength
Standard wavelength:
266nm, 355nm, 532nm, 632.8nm, 800nm, 850nm, 980nm, 1064nm, 1310nm, 1550nm
Waveplate
